INPUTS

INPUT
impedance 500 Kohm, max. voltage 15 Vpp
BALANCED INPUT (XLR)
impedance 100 Khom, max. voltage 25 Vpp
EFFECT RETURN
impedance 33 Kohm, max. voltage 10 Vpp

CONTROLS

GAIN
-60 dB to +23 dB range
TUBE DRIVE (6205 tube)
MASTER VOLUME
LINE OUT LEVEL
GROUND LIFT
switch on rear panel
PRE/POST EQ
switch on rear panel

EQUALIZATION

LOW
center frequency: 40 Hz; level: ±16 dB
LOW MID
center frequency: 360 Hz, level: ±16 dB
HIGH MID
center frequency: 800 Hz, level: ±16 dB
HIGH
center frequency: 10 kHz, level: ±16 dB

VPF (Variable Pre-shape Filter)
center frequency 380 Hz (cut)
VLE (Vintage Loudspeaker Emulator)
frequency range 250 Hz-20 kHz (cut)


OUTPUT

LINE OUT
balanced XLR, max. voltage 20 Vpp
EFFECT SEND
unbalanced, max. voltage 20 Vpp (pre-EQ)
TUNER OUT
unbalanced, max. voltage 2 Vpp
SPEAKER OUT
speakon/1/4" combo, 1/4"


OTHER

NOTES:
Minimum ohm load for all Markbass heads is 4 ohms.

Markbass amps/combos are manufactured to be sold and used in the country of purchase, and they are factory preset to that country’s voltage.
Due to homologation issues, the voltage may not be changed.

Rack ears do not come included with this head.

The Little Mark Rocker features a single 6205 miniature tube.

Product specifications are subject to change without notice



One of the main reasons for the Little Mark's incredible international success has been its versatile sound, which makes it suitable for any style of music! But since it's so often the choice of ROCK bass players, we decided to make a more aggressive version, adding custom-designed tube drive circuity for a wide range of onboard overdrive and distortion sounds. For those about to rock—we are proud to present: the ultra-cool LITTLE MARK ROCKER!
