CMD SUPER COMBO K1

CMD SUPER COMBO K1

Product code: MBC105029Z

The new ALAIN CARON signature CMD SUPER COMBO K1 has been developed respecting Alain's high standards.
This 3-ways combo is amplified by a powerful 1000W MPT (Mark Proprietary Technology) power amp to offer the best fidelity, dynamic and a very serious headroom!
Top-quality sound, incredible power, simple and effective controls... make this combo SUPER!



Markbass amps/combos are manufactured to be sold and used in the country of purchase, and they are factory preset to that country’s voltage. Due to homologation issues, the voltage may not be changed.

Product Discontinued

Specifications:

Additional information

POWER

SERIES

SIZE

SPEAKER CONFIG

Tweeter

Technical Features

INPUTS

INPUT impedance 500 Kohm, max. voltage 15 Vpp

EFFECT RETURN impedance 33 Kohm, max. voltage 10 Vpp

CONTROLS

GAIN Range –60 / 23 dB VPF (Pre shape center frequency 380Hz)

LINE OUT GND Lift – Pre/Post EQ MASTER

EQUALIZATION

LOW

MID

LOW

MID

HIGH HIGH

OUTPUTS

LINE OUT, Max Voltage 20 Vpp

SEND Unbalanced, Max Voltage 20Vpp (Pre EQ)

TUNER OUT Unbalanced, Max Voltage 2Vpp

SPEAKERS

SIZE 1X12″ + 1X5″

POWER HANDLING 800W RMS (AES Standard)

IMPEDANCE 8 ohms

TWEETER

1” coil compression tweeter

FREQUENCY RESPONSE

40Hz to 20KHz

CROSSOVER FREQUENCIES

1.5 KHz / 5.5 KHz

SENSITIVITY

99dB SPL

POWER AMP

OUTPUT POWER 600W RMS@8 ohm / 1000W RMS@4 ohm

REFLEX

REAR

OTHER

WEIGHT 59.75 lbs / 27,1 Kg

WIDTH 14.76 in. / 37,5 cm DEPTH 17.32 in. / 44 cm HEIGHT 27.17 in. / 69 cm

POWER REQUIREMENT 100/120V; 230V; 240V 50/60Hz (Voltage is factory preset according to region of sale)
